| 型號 | 字符X行數 | 外形尺寸 WxHxT(mm) |
視域尺寸 WxH(mm) |
點尺寸 WxH(mm) |
模塊電壓 | 背光類型 | 控制器 | 產品圖片 |
SYB12864XV10  |
128x64 | 63.2*54.0*9.5 | 54.0*35.9 | 0.35*0.45 | 5V | LED | AIP31107/8 | 圖片 |
| SYB12864L2V11 |
128*64 | 78.0*70.012.5 | 62.0*44.0 | 0.40*0.56 | 5Vor3V | LED | AIP31107/08 | 圖片 |
| SYB12864C2L1-2 |
12864 | 78.0*70.0*12.5 | 62.0*44.0 | 0.40*0.56 | 5Vor3.3V | LED | AIP31107/8 | 圖片 |
| SYB12864L1V11 |
128*64 | 78.0*70.0*12.5 | 62.0*44.0 | 0.40*0.56 | 5Vor3V | LED | AIP31107/8 | 圖片 |
| SYB12864LV10 |
128*64 | 78.0*70.0*12.5 | 62.0*44.0 | 040*0.56 | 5Vor3.3V | LED | AIP31107/8 | 圖片 |
| SYB12864LV10 |
128*64 | 78.0*70.0*12.5 | 62.0*44.0 | 0.40*0.56 | 5Vor3V | LED | AIP31107/8 | 圖片 |
| SYB12864LV10 |
128*64 | 78.0*70.0*12.5 | 62.0*44.0 | 0.40*0.56 | 5Vor3V | LED | AIP31107/8 | 圖片 |
| SYB12864K5V10 |
12864 | 93.0*70.0*14 | 72.0*39.0 | 0.48*0.48 | 3.3v，5v | LED | ST7920 | 圖片 |
| SYB12864IV20 |
128*64 | 54.0*50.0*6.2 | 43.5*29.0 | 0.28*0.35 | 5V | LED | AIP31107/8 | 圖片 |
